Light Truck Engine D28

Light Truck Engine D28
Light Truck Engine D28
Market Type:

After Market

Current Export Market:

North America,South America,Western Europe,Eastern Europe,Eastern Asia,Southeast Asia,Mid East,Africa,Oceania

Product Details

Product Name:

Light Truck Engine D28

Application:

Light Truck, Light Bus

Product Description:

Engine Structure:
1. Crank
2. Valve
3. Supply system
   1)Intake and exhaust system
   2)Fuel supply system
4. Lubrication system
5. Cooling System
6. Starting System

Item
 D28D10-3D1
Diesel engine type Water cooling, Four-stroke, Inline, Overhead valve
Combustion Type Direct injection
Cylinder Chrome-plated cylinder of dry
Number of cylinders-Cylinder*Stroke(mm) 4-93*102
Number of rings 2 Gas rings,2 Oil ring
Piston Displacement(L) 2.771
Compression ratio 17.5
Engine power(KW/rpm) 75/3600
Engine torque(Nm/rpm) 230/2000
Idle speed(rpm) 750~850
Net mass(Kg) 230~240
Cylinder working order 1-3-4-2
Injection timing (before TDC) 8~12
Fuel grade 0 # light diesel oil(Northern winter -10 # light diesel oil)
Intake and exhaust valve clearance(mm) 0.40(Cold)
Intake valve open Before TDC 24.5
Intake valve off After BDC 55.5
Exhaust valve open Before BDC 54.0
Exhaust valve off After BDC 26.0
Lubrication Pressure cycle splash compound
Oil Grade API   CF-4
SAE    15W-40
Oil Capacity(L) 4.0(Oil change)
Oil Pressure(Kpa) 98(Idle)   441(2000rpm)
Oil cooling type Closed loop Water cooling pressure
Minimum fuel consumption(g/kw.h) 212g/kw.h
Pump Type VE pump electronic control
Nozzle type P-type porous-type (5 hole)
Injector opening pressure(Mpa) 27
Engine(V-A) 14-80
Starter(V-KW) 12-2.8
Crank
Light Truck Engine D28
Light Truck Engine D28
